Figure 13. Écran Surintensité instantanée (Instantaneous Overcurrent) (50-3)
Current Courant
Instantaneous Overcurrent (50-3) Surintensité instantanée (50-3)
Instantaneous Overcurrent Surintensité instantanée
50-3 Element (50P)
Mode
3 Phase
Source CT Circuit 1
Pickup (Secondary A)
Time Delay (ms)
Direction
Non-Directional Élément 50-3 (50P)
Mode
Triphasé
Circuit TC 1 Source
Enclenchement (courant secondaire A)
Temporisation (ms)
Sens
Non directionnel
Figure 14. Page logique 1 (Logic Page 1) BESTlogicPlus
BE1-11g Démarrage rapide
