6 Programmation DIN
6.16 Cy
cles de dég
a
g
e
ments
Angle du dégagement (pour DIN 509 E et F): 15°
Angle transversal (pour DIN 509 F): 8°
Paramètres du dégagement DIN 509 E (cotes en mm)
Diamètre
Profondeur
dégagement I
Longueur
dégagement K
Rayon
dégagement R
< 18
0,25
2
0,6
> 18 - 80
0,35
2,5
0,6
> 80
0,45
4
1
Paramètres du dégagement DIN 509 F (cotes en mm)
Diamètre
Profondeur
dégage-
ment I
Longueur
dégage-
ment K
Rayon
dégage-
ment R
Profondeur
trans-
versale P
< 18
0,25
2
0,6
0,1
> 18 - 80
0,35
2,5
0,6
0,2
> 80
0,45
4
1
0,3
