Yaskawa A1000 CIMR-AU - Manuel (Page 34)

n Variateurs IP20/NEMA Type 1
Note: le retrait du couvert de protection supérieur ou du support de conduit inférieur d’un variateur de vitesse à boîtier IP20/NEMA Type 1
annule la protection NEMA Type 1 tout en maintenant la conformité IP20.
L1
4-d
H1
H
H0
H2
H3
L L2 Max. P
P1
t2
t1
Figure 2 Figure 1
L1
H4
H
H0 H1
H3 H2
P
P1
t1
4-d
L L2 Max.
Table 2.2 Dimensions du boîtier IP20/NEMA Type 1: classe de 200 V
Modèle de
variateur de
vitesse
CIMR-Ao2A
Dimensions mm (po)
Figure L H P L1 L2 H0 H1 H2 H3 H4 P1 t1 t2 d
Poids
kg (lb)
0004F
1
<1>
140
(5.51)
300
(11.81)
147
(5.79)
122
(4.80)
–
260
(10.24)
248
(9.76)
6
(0.24)
40
(1.57)
1.5
(0.06)
38
(1.50)
5
(0.20)
– M5
3.3
(7.3)
0006F
140
(5.51)
300
(11.81)
147
(5.79)
122
(4.80)
–
260
(10.24)
248
(9.76)
6
(0.24)
40
(1.57)
1.5
(0.06)
38
(1.50)
5
(0.20)
– M5
3.3
(7.3)
0008F
140
(5.51)
300
(11.81)
147
(5.79)
122
(4.80)
–
260
(10.24)
248
(9.76)
6
(0.24)
40
(1.57)
1.5
(0.06)
38
(1.50)
5
(0.20)
– M5
3.4
(7.5)
0010F
140
(5.51)
300
(11.81)
147
(5.79)
122
(4.80)
–
260
(10.24)
248
(9.76)
6
(0.24)
40
(1.57)
1.5
(0.06)
38
(1.50)
5
(0.20)
– M5
3.4
(7.5)
0012F
140
(5.51)
300
(11.81)
147
(5.79)
122
(4.80)
–
260
(10.24)
248
(9.76)
6
(0.24)
40
(1.57)
1.5
(0.06)
38
(1.50)
5
(0.20)
– M5
3.4
(7.5)
0018F
140
(5.51)
300
(11.81)
164
(6.46)
122
(4.80)
–
260
(10.24)
248
(9.76)
6
(0.24)
40
(1.57)
1.5
(0.06)
55
(2.17)
5
(0.20)
– M5
3.8
(8.2)
0021F
140
(5.51)
300
(11.81)
164
(6.46)
122
(4.80)
–
260
(10.24)
248
(9.76)
6
(0.24)
40
(1.57)
1.5
(0.06)
55
(2.17)
5
(0.20)
– M5
3.8
(8.2)
0030F
140
(5.51)
300
(11.81)
167
(6.57)
122
(4.80)
–
260
(10.24)
248
(9.76)
6
(0.24)
40
(1.57)
1.5
(0.06)
55
(2.17)
5
(0.20)
– M5
4.2
(9.3)
0040F
140
(5.51)
300
(11.81)
167
(6.57)
122
(4.80)
–
260
(10.24)
248
(9.76)
6
(0.24)
40
(1.57)
1.5
(0.06)
55
(2.17)
5
(0.20)
– M5
4.2
(9.3)
0056F
180
(7.09)
340
(13.39)
187
(7.36)
160
(6.30)
–
300
(11.81)
284
(11.18)
7.9
(0.31)
40
(1.57)
1.5
(0.06)
75
(2.95)
5
(0.20)
– M5
5.9
(13.0)
0069F
220
(8.66)
400
(15.75)
197
(7.76)
192
(7.56)
–
350
(13.78)
335
(13.19)
7.9
(0.31)
50
(1.97)
1.5
(0.06)
78
(3.07)
5
(0.20)
– M6
9
(20.1)
0081F
220
(8.66)
400
(15.75)
197
(7.76)
192
(7.56)
–
350
(13.78)
335
(13.19)
7.9
(0.31)
50
(1.97)
1.5
(0.06)
78
(3.07)
5
(0.20)
– M6
10
(22.0)
0110F
2
<1>
254
(10.00)
534
(21.02)
258
(10.16)
195
(7.68)
7.9
(0.31)
400
(15.75)
385
(15.16)
7.7
(0.30)
134
(5.28)
1.5
(0.06)
100
(3.94)
2.2
(0.09)
2.286
(0.09)
M6
23
(50.7)
0138F
279
(10.98)
614
(24.17)
258
(10.16)
220
(8.66)
7.9
(0.31)
450
(17.72)
435
(17.13)
7.7
(0.30)
164
(6.46)
–
100
(3.94)
2.2
(0.09)
2.286
(0.09)
M6
28
(61.7)
0169F
329
(12.95)
730
(28.74)
283
(11.14)
260
(10.24)
7.9
(0.31)
550
(21.65)
535
(21.06)
7.7
(0.30)
180
(7.09)
–
110
(4.33)
2.2
(0.09)
2.286
(0.09)
M6
41
(90.4)
0211F
329
(12.95)
730
(28.74)
283
(11.14)
260
(10.24)
7.9
(0.31)
550
(21.65)
535
(21.06)
7.7
(0.30)
180
(7.09)
–
110
(4.33)
2.2
(0.09)
2.286
(0.09)
M6
42
(92.6)
2.1 Installation mécanique
34 YASKAWA ELECTRIC Manuel de mise en route rapide du variateur de vitesse c.a. Yaskawa – A1000 (TOFP C710616 41C)
