102 9440370990 Rev H
L-L Voltage {p.u}, Iavg: Avg Line Current {p.u}, Iaux: Cross Current Input {p.u}, Vfd: Field Voltage {p.u},
Ifd: Field Current {p.u}, Vaux: Aux Voltage Input {p.u}, kW: Real Power {p.u.}, kvar: Reactive Power {p.u.},
kVA: Total Power {p.u.}, PF: Power Factor, V1: Positive Sequence Voltage {p.u.}, V2: Negative Sequence
Voltage {p.u.}, I1: Positive Sequence Current {p.u.}, I2: Negative Sequence Current {p.u.}, G Hz:
Generator Frequency (Hz), B Hz: Bus Frequency {Hz}, Test: Frequency Response Signal {p.u.} ou Ptest:
Time Response Signal {p.u.}, TermF: Terminal Frequency Deviation {%}, CompF: Compensated
Frequency Deviation, PssKW: Pss Electric Power {p.u.}, Vtmag: PSS Term Voltage,x2 : Speed HP
#1,WashW : Washed Out Speed {p.u.},x5 : Power HP #1 {p.u.}, WashP: Washed Out Power {p.u.}, x7:
Mechanical Power {p.u.}, x8: Mechanical Power LP #1, x9: Mechanical Power LP #2, x10: Mechanical
Power LP #3, x11: Mechanical Power LP #4, MechP: Filtered Mechanical Power {p.u.}, Synth:
Synthesized Speed {p.u.}, Tflt1: Torsional Filter #1 {p.u.}, x29: Torsional Filter #2 {p.u.}, x15: Lead-Lag #1
{p.u.}, x16: Lead-Lag #2 {p.u.}, x17: Lead-Lag #3 {p.u.}, x31: Lead-Lag #4 {p.u.}, Prelim: Pre-Limit Output
{p.u.}, Post: Post-Limit Output {p.u.}, POut: Final PSS Output {p.u.}, CntOp: Control Output {p.u.}, TrnOp:
Internal State {p.u.}, ErrIn: Avr Error Signal, OelOutput: OEL Controller Output, UelOutput: UEL Controller
Output, SclOutput: SCL Controller Output, varLimOutput: var Limiter Output, NullBalance: Null Balance
Level {p.u.}, PositionInd: Position Indication {p.u.}, AvrOut, FcrErr, FcrState, FcrOut, FvrErr, FvrState,
FvrOut, var/PfErr, var/PfState, var/PfOut, OelState, UelState, SclState, varLimState, Droop,Rcc, OelRef,
UelRef, SclIRef, SclPfRef, varLimRef, ProgrammableDiagnotic1, ProgrammableDiagnotic2,
ProgrammableDiagnotic3, ProgrammableDiagnotic4, ProgrammableDiagnotic5, or
ProgrammableDiagnotic6.
C Trending Duration (durée de l'enregistrement des tendances) : réglable entre 1 et 720 heures par
incréments de 1 heure.
0BEnregistrement d’événements DECS-250
