186 Chapter 5 - 4 cm/14 cm Viewfinders
14 cm Viewfinder
B1707M00LD
September 2000
THOMSON TTV1707 / CCU DT500
User manual
5.2 - 14 CM VIEWFINDER
5.2.1 - Main characteristics
• Resolution: 600 TV lines.
• Input signal: 1 V peak-to-peak/1 K
Ω or 75 Ω (switchable).
• Supply voltage: 11 to 17 Volts.
• Consumption: approximately 12 W with the video signal and antenna indicator lights lit.
• Dimensions: 290 x 148 x 134 mm.
• Geometry and linearity: line < 3%, field < 2%.
• Weight: approximately 3 kg.
CAUTION:
To prevent any risk of destruction, do not expose this viewfinder to rain or humidity.
Due to the high voltages used in the viewfinder, the cover is to be removed by qualified
personnel only.
