Chapter 3 - Camera - DC/DC Converter 155
Camera Description
THOMSON TTV1707 / CCU DT500
User manual
B1707M00LD
September 2000
3. «VIDEO RET 1-2» selector switch Selection of the external video number,
RET1 or RET2, displayed in the viewfinder
when the external video is selected using the
«RET» button on the lens. The display is
either permanent or momentary (refer to the
«Description of cameraman operating func-
tions» paragraph in this chapter. The RET1
and RET2 videos are applied to the back of
the Channel Control Unit.
Note :
1) Transmission of external videos depends
on the length of the triaxial cable. Refer
to the SPECIFICATION chapter.
2) the «RET2» video is available if the
«PROMPTER» option is installed in the
camera.
4. "MENU ↑, ↓" and «MENU +,-» selector
switches.
Display and modification of Cameraman
functions:
• «MENU
↑, ↓» buttons: Display the
Cameraman’s operating functions and
enable the cursor to be moved to select the
function to be modified.
• «MENU +,-» buttons:
• Used to modify the operating functions
selected using the «MENU ↑, ↓»
buttons.
• If the operating functions are not
displayed, these buttons select
(permanent manner "MENU -", or
momentary manner "MENU +") the
RET1 or RET2 video displayed in the
viewfinder. The "RET1" or "RET2"
signal selection is made by the
"VIDEO RET" switch.
For details of the operating functions, refer
to the 3.3.2 - Cameraman operating func-
tions paragraph in this chapter.
VIDEO RET
1
2
+
-
MENU
