Chapter 1 - Specifications 119
Presentation
THOMSON TTV1707 / CCU DT500
User manual
B1707M00LD
September 2000
“DC OUT” source to supply auxiliary equipment
A 30 to 52 V DC supply is available on the back of the camera to supply an external
converter (available as option) attached to the camera baseplate.
Two types of converter can be connected:
• 13 V DC/50 W output voltage converter
• 24 V DC/50 W output voltage converter.
NOTE: The maximum power (50W) produced by the converter is ensured with a maximum
triaxial cable length. Refer to the 1.1.4 - Length of the triaxial cable Camera/Channel
Control Unit paragraph.
ASSOCIATED CAMERAS
Due to an identical control system, the 1707 camera can be fully integrated into a type
TTV1657, TTV1657D or 1557D camera environment.
