114 Chapter 1 - Specifications
Principal characteristics
B1707M00LD
September 2000
THOMSON TTV1707 / CCU DT500
User manual
1.1.3 - DC-to-DC converters
The external DC-to-DC converter is provided as an option. This is supplied from the
non-regulated voltage produced on the “DC OUT” receptacle of the camera and is mecha-
nically attached to the camera baseplate. The purpose of this converter is, for example, to
produce a DC voltage to supply a PROMPTER.
Two types of converter can be supplied:
• A converter with a 13 V DC / 50 W output.
• A converter with a 24 V DC / 50 W output.
NOTE: It is not possible to connect several converters to the camera simultaneously.
Input voltage
30 to 52 V DC (+10%/-20%)
Output voltage
13 V DC (± 5%) or 24 V DC (± 5%) depending on type of converter
Maximum output power
50 Watts
Weight:
approximately 0.36 kg
Environment:
In operation: - 20°C to + 45°C - relative humidity 95% condensation-free
Storage: - 20°C to + 55°C - relative humidity 95% condensation free.
Electromagnetic compatibility and safety devices:
Conforms with CE directives (CE marking)
