Chapter 4 - Channel control unit

173

Description

THOMSON TTV1707 / CCU DT500

User manual

B1707M00LD
September 2000

2. «MIC OUT» receptacle

Audio output from ambient microphone
connected to camera.
The nominal output level is 0 dB. To
modify this level, refer to the «INSTAL-
LATION» chapter.

3. «INTERCOM» receptacle

Connection of intercommunication network

between the Cameraman and producer.

The nominal input and output levels are 0
dB. To alter these levels, refer to the
«INSTALLATION» chapter.
The link may be «4-wire» or «RTS».
Refer to the «INSTALLATION» chapter.

4. «REMOTE» receptacle

Connection of remote control panel.

The link is an RS422 link:

The «PV RCP» 12 V voltage is used to
supply the panel (Pmax=6W).
The «ON AIR1» and «ON AIR2»
signals to the OCP and the camera are
added to the «PV RCP».

MIC OUTPUT

2

3

1

Male receptacle

Type: XLR-3-32
P/N: 91.355.161

Corresponding
socket

Type: XLR-3-11C
P/N: 91.355.160

1 : GND
2 : MIC X OUT
3 : MIC Y OUT

INTERCOM

1

6

9

5

Female receptacle
Type: DEP09S400T
P/N: T9001515

Corresponding
socket
Type:
PMD2T09+Z-HE5-M2
P/N: 99.155.568

1 : GND
2 : IN Y
3 : OUT X
4 : CH1 RTS
5 : CH2 RTS (Not used)

6 : Not connected
7 : IN X
8 : OUT Y
9 : GND

INTERCOM

CH1

RTS

Y X

OUT

Y X

IN

1

6

9

5

REMOTE

1

6

9

5

Female receptacle
Type: DEP09S400T

P/N: T9001515

Corresponding

socket
Type:
PMD2T09+Z-HE5-M2
P/N: 99.155.568

1 : GND
2 : RETURN A2
3 : GO B2
4 : GND
5 : PV RC

6 : GND
7 : RETURN B2
8 : GO A2
9 : GND

CCU

OCP

RETURN A

RETURN B

OUT A

OUT B

PV RCP

GROUND

4

5

3

8

7

2
