3.1.2 - Right-hand side
1. Base for accessory attachment
2. Attaching bases for the 14 cm viewfinder
3. Attachments of carrying strap
4. Camera identification. The camera is identified on installation by
means of the figures delivered with the equi-
pment.
Attachment of the camera is made by means
of a magnetised fitting.
1
2
3
4
5
9
8
7
6
10
11
12
13
14
Support for
attachment of camera
handle
Supports for attachment at
the back of the camera
