Chapter 2 - Installation 145
Operator’s control panel
THOMSON TTV1707 / CCU DT500
User manual
B1707M00LD
September 2000
CCU OCP
GROUND
GROUND
RETURN A
RETURN B
OUT B
OUT A
GROUND
GROUND
OCP POWER SUPPLY
(+ ON AIR 1, ON AIR 2)
GROUND
OUT A
OUT B
RETURN B
RETURN A
GROUND
GROUND
OCP POWER SUPPLY
(+ ON AIR 1, ON AIR 2)
GROUND
5
4
3
2
1
6
7
8
9
5
4
3
2
1
6
7
8
9
1 OR 15 OR 50 METRES CABLE BETWEEN CCU OCP
Cable Shield
CCU OCP
GROUND
RETURN A
RETURN B
OUT B
OUT A
GROUND
OCP POWER SUPPLY
(+ ON AIR 1, ON AIR 2)
GROUND
OUT A
OUT B
RETURN B
RETURN A
GROUND
OCP POWER SUPPLY
(+ ON AIR 1, ON AIR 2)
100 METRES CABLE BETWEEN CCU OCP
5
4
3
2
1
6
7
8
9
5
4
3
2
1
6
7
8
9
Cable Shield
