212
Chapter 6 - Version SPORTCAM TTV1657D
Installation
B1685902AC
September 2000
THOMSON EFP1685/CCU1686
User manual
6.1.4 - Installing the 17 cm viewfinder
1. Pull the lever, then engage the viewfinder in the dovetail.
2. Connect the 17 cm viewfinder plug.
Lever
Dovetail
LENS
CAM V/F
ON AIR 1 indication
Viewfinder plug
