Chapter 2 - Installation 145
Audio
THOMSON EFP1685 / CCU1686
User manual
B1685902AC
September 2000
2.3.3.2 - RTS1 and RTS2 to cameraman links
The Cameraman receives the sound from the RTS1 line in the lefthand earphone and the
Sound from the RTS2 line, to which the PROG and CCU Sounds may be added, in the
righthand earphone.
Installation of RTS type audio
EXTERIOR
Common
External RTS lines
CHANNEL
CONTROL UNIT
(LH earphone)
MIC
DECODER
to/from
CAMERA
(RH earphone)
"STEREO INTERCOM" PCB
CHANNEL CONTROL UNIT
POWER SUPPLY
Regulator
Regulator
Regulator
Power supply
Mains supply
VTR Telecinema
Producer Mixer
RTS1 and 3
RTS1 and 2
1x5 distributor
Technical
Control Room
(ENG)
Channel
Control Unit
Channel
Control Unit
Channel
Control Unit
Camera Camera Camera
RTS1: "Producer"/"Cameraman" link
RTS2: "Technical Control Room"/"Cameraman" link
RTS3: "Producer"/VTR, Operators, Telecinema and other links.
