Chapter 6 - Version SPORTCAM TTV1657D 205
THOMSON EFP1685/CCU1686
User manual
B1685902AC
September 2000
Chapter 6
Version SPORTCAM TTV1657D
6.1 - Installation ................................................................... 207
6.1.1 - Fitting the heavy lens......................................................................... 207
6.1.2 - Fitting the camera with a heavy lens ................................................. 208
6.1.3 - Fitting with a light lens ....................................................................... 210
6.1.4 - Installing the 17 cm viewfinder........................................................... 212
6.1.5 - Fitting the script-holder ...................................................................... 213
6.2 - Description .................................................................. 214
6.2.1 - Connectors and selector switches located on the bottom casing of the
"SPORTCAM" chassis .................................................................................. 215
6.2.1.1 - Right-hand side.............................................................................. 215
6.2.1.2 - Left-hand side ................................................................................ 216
6.2.1.3 - Front panel..................................................................................... 217
6.2.1.4 - Top surface .................................................................................... 218
6.2.2 - Cables delivered with the "SPORTCAM" chassis.............................. 219
6.2.2.1 - 17 cm viewfinder cable .................................................................. 219
6.2.2.2 - Lens cable for "THOMSON" front side........................................... 219
6.2.2.3 - Lens cable for "SONY" front side................................................... 220
6.2.2.4 - Lens cable for "CANON" front side ................................................ 221
6.2.2.5 - Viewfinder to "SPORTCAM" camera casing cable ........................ 222
6.2.3 - Rear keyboard ................................................................................... 223
6.2.3.1 - "VF SELECTION" section .............................................................. 223
6.2.3.2 - "MENUS" section ........................................................................... 223
6.2.3.3 - "CALL" button ................................................................................ 223
6.2.4 - B/W 17 cm viewfinder ........................................................................ 224
6.2.4.1 - Graticle keyboard........................................................................... 224
6.2.4.2 - Picture controls .............................................................................. 225
6.2.4.3 - Antenna indicators light.................................................................. 225
