Grass Valley EFP1685 - Manuel (Page 123)

Chapter 1 - Generality 123
Control panels which can be connected to the equipment
THOMSON EFP1685 / CCU1686
User manual
B1685902AC
September 2000
1.1 - CONTROL PANELS WHICH CAN BE CONNECTED TO
THE EQUIPMENT
The TTV 1657D camera connected to the EFP1685/CCU1686 system is operated with
OCP40 / OCP42. Several cameras must be centralized with a MCP (Master Control Panel).
Refer to the panels manual.
