200 Chapter 5 - Use
Description of operating displays
B1685902AC
September 2000
THOMSON EFP1685/CCU1686
User manual
• GAIN: Indicates the partial Red and Blue gain correction made by the control panel.
NOTE : Operation of green gain alters the red and blue partial gains.
• BLACK: Indicates the Red, Green and Blue partial black correction value provided
by the control panel.
• ND: Indicates the density of the filter selected on the camera. The CAP indication
indicates that the lens is closed off.
The figure displayed to the right of the filter type indicates the equipment number
(defined by the thumbwheel on the front of the APCM board).
• EF: Indicates the effect filter selected or "CLEAR" if the camera is not equipped with
an effect filter.
• FX2: Indicates whether the focal length doubler is in use.
• IRIS: Indicates whether the iris is operating in the AUTOmatic mode (aperture
slaved to video level) or in the MANUal mode (aperture control by control panel
joystick).
• SHUT: Indicates whether the shutter is active and, if so, the speed selected.
NOTE : SHUT is substitued for CLSC (and value) when the Clear Scan is selected.
• PED: Indicates the correction value made by the master black (Master Ped) control
on the control panel.
5.1.5 - Operating display
Activated and disabled by pressing the "CCU STATUS" button.
If the operating display is not selected, status display is selected automatically.
XXXXXX : XXX
XXXXXX : XXX
XXXXXX : XXX
XXXXXX : XXX
XXXXXX : XXX
AIR2
AIR1
CCU: X
CAM: X
W, S, C
F: X,X
