Chapter 3 - 1685/1686 Channel Control Unit 169
CCU1685
THOMSON EFP1685/CCU1686
User manual
B1685902AC
September 2000
PIX Video output with
sync intended for
PM monitor. Socket
Type: BNC50-EFDPEI-Y3
P/N: T9001518 Level 1 V/75 Ohms.
The output video is selected at
the control panel.
Various displays may be inlaid
in the monitor video (refer to
chapter 2 "Installation" and to
chapter 5 "Operation").
ENC. OUT Encoded video out-
puts. 3 Sockets
Type: BNC50-EFDPEI-Y3
P/N: T9001518 Level 1 V/75 Ohms.
VIDEO OUT
1
Output video
signals.
3 Sockets
Type: BNC50-EFDPEI-Y3
P/N: T9001518
The outputs can be R,G,B or Y,
R-Y, B-Y component configu-
red. Sync signals can be added
to the green video (common to
OUT 2 VIDEO). Refer to
chapter 2 "Installation".
Level 700 mV/75 Ohms unless
1 V/75 Ohms on green video if
sync signal present.
R (R-Y)
G (Y)
B (B-Y)
VIDEO OUT
2
Output video
signals.
3 Sockets
Type: BNC50-EFDPEI-Y3
P/N: T9001518
The outputs can be R,G,B or Y,
R-Y, B-Y configured. Sync
signals can be added to the
green video (common to
VIDEO OUT 1). Refer to
chapter 2 "Installation".
Level 700 mV/75 Ohms unless
1 V/75 Ohms on green video if
sync signal present.
R (R-Y)
G (Y)
B (B-Y)
