Chapter 2 - Installation 147
Video
THOMSON EFP1685 / CCU1686
User manual
B1685902AC
September 2000
2.4.2 - "SYNC SIGNAL ON/OFF" selection for green output video
signals
On the video board, set selector switch S03 (G.SYNC: ON/OFF) to the appropriate posi-
tion.
NOTE : This switch has no effect if the output videos are the "COMPONENTS" and
the "Y" signal, which always include the sync signal.
2.4.3 - "Y"/ENCODED" selection of PM control signal at channel
control unit output
On the video board, set selector switch S10 (PIX MON: Y.VIDEO/ENCODED) to the
appropriate position.
Front
panel
"VIDEO"/"VIDEO PIP" PCB (CCU)
G. SYNC
ON OFF
S3
Front
panel
"VIDEO"/"VIDEO PIP" PCB (CCU)
PIX MON
S10
ENCODED
Y VIDEO
