Chapter 4 - Rear adapter 191
Rear panel
THOMSON EFP1685/CCU1686
User manual
B1685902AC
September 2000
5. Camera - Channel control interconnection triaxial cable socket
10
BLA
EXT or MIX
VIDEO
30
AM
GREEN
VIDEO
50
AM
RED
VIDEO
70
AM
BLUE
VIDEO
154
AM
TELEPROMPTER
F (MHZ)
LF BAND
230V DC
CCU
TO CAM
CAM
TO CCU
320 KHZ
.M
H CTRL
640 KHZ
AM
V CTRL
1,28 MHZ
AM
PCM
2,5 MHZ
AM
PCM
3,58 MHZ
FM
INCOM
CAM
4,52 MHZ
FM
INCOM
ENG+
PROG
SOUND
4,0 MHZ
FM
MIC CA
4,26 MHZ
FM
INCOM
PROD
5,06 MHZ
FM
MIC CAM
230V DC
Distribution of frequency spectrums along cable
