Chapter 6 - Version SPORTCAM TTV1657D 211
Installation
THOMSON EFP1685/CCU1686
User manual
B1685902AC
September 2000
6. Fit the lens.
7. Connect the cables as follows:
• cable No. 1 (from CAM V/F plug on bottom casing) to V/F receptacle on camera,
• lens cable to LENS receptacle on camera.
LENS
CAM V/F
