Chapter 5 - Use 203
Description of operating displays
THOMSON EFP1685/CCU1686
User manual
B1685902AC
September 2000
• WHITE: Indicates the corrections made individually to the R and B videos by the
white adjustment automatic device to balance the R and B peak values on green. The
correction range is between + 99 and - 99. Above or below these values, the white
level adjustment is not performed correctly and BAD is displayed.
• T: Indicates the lighting temperature determined by the white balancing automatic
device as a function of the corrections made to the red and blue levels.
