198
Description of operating displays
B1685902AC
September 2000
THOMSON EFP1685/CCU1686
User manual
5.1.2 - Control panel(s) configuration display
Since the control panel(s) are locked on power-on, this screen is displayed on chan-
geover to the non-locked mode on the control panel or one of the control panels.
• OCPX PRIO:X: Indication of the type and number of the control panel connected to
the equipment, followed by the priority number for this panel. For multi-control
panel operation, the supplementary control panel(s) will be displayed above this
indication.
• CAM:X : Indication of CAM number (corresponds to the NUMBER in the OCP
SETTING).
• CCU:X : Indication of CCU number (corresponds to the number of the thumbwheel
on the front of the APCM board).
• F:X.X :Indicates the iris aperture or CLOSE, if the latter is closed.
5.1.3 - Alarm displays
This/these message(s) is/are displayed when an equipment malfunction(s) is/are
detected. The alarm messages displayed during the startup phase do not indicate an
equipment defect.
• OPEN CABLE: Indicates that the triaxial cable is not correctly connected.
• CAM OFF: Indicates that the selector switch on the CA85 is set to "OFF".
• NO CAM SYNC: Indicates that the sync signals from the camera are not being
detected.
• NO DATA CCU CAM: Indicates that there is no remote control between the CCU
and the camera.
• NO DATA CAM CCU: Indicates that there is no return remote control between the
camera and the CCU.
CCU:X
CAM:X
OCPX
PRIO:X
F:X.X
