Powermax125 Manuel de service 808072
8 – Dépannage et tests du système
Figure 23
J22
J21
J20
J19
J27
WORK
LEAD
J26
+
_
+
_
TP7
TP9
TP8
W
R
B
325 V c.c.
405 V c.c.
270 V c.c.
255 V c.c.
650 V c.c.
325 V c.c.
810 V c.c.
405 V c.c.
540 V c.c.
270 V c.c.
510 V c.c.
255 V c.c.
Entrée 480 V CSA
IGBT de l’onduleur
Entrée 600 V CSA
Entrée 400 V CE
Entrée 380 V CCC
Condensateurs de masse
