10 Programmation: Paramètres Q
288
Nom du groupe, n° ident.
Numéro
Indice
Donnée-système
Transformations actives, 210
1
–
Rotation de base en mode Manuel
2
–
Rotation programmée dans le cycle 10
3
–
Axe réfléchi actif
0: image miroir inactive
+1: axe X réfléchi
+2: axe Y réfléchi
+4: axe Z réfléchi
+64: axe U réfléchi
+128: axe V réfléchi
+256: axe W réfléchi
Combinaisons = somme des différents axes
4
1
Facteur échelle actif axe X
4
2
Facteur échelle actif axe Y
4
3
Facteur échelle actif axe Z
4
7
Facteur échelle actif axe U
4
8
Facteur échelle actif axe V
4
9
Facteur échelle actif axe W
5
1
ROT. 3D axe A
5
2
ROT. 3D axe B
5
3
ROT. 3D axe C
6
–
Inclinaison plan d'usinage active/inact. (-1/0)
Décalage actif du point zéro, 220
2
1 à 9
Indice 1=axe X
2=axe Y
3=axe Z
Indice 4=axe A
5=axe B
6=axe C
Indice 7=axe U
8=axe V
9=axe W
Plage de déplacement, 230
2
1 à 9
Commut. fin de course logiciel négatif
Axes 1 à 9
3
1 à 9
Commut. fin de course logiciel positif
Axes 1 à 9
Position nominal dans
1
1 à 9
Indice 1=axe X
2=axe Y
3=axe Z
système REF, 240
Indice 4=axe A
5=axe B
6=axe C
Indice 7=axe U
8=axe V
9=axe W
Position nominale dans le
1
1 à 9
Indice 1=axe X
2=axe Y
3=axe Z
système d'introduction, 270
Indice 4=axe A
5=axe B
6=axe C
Indice 7=axe U
8=axe V
9=axe W
Etat de M128, 280
1
–
0: M128 inactive, -1: M128 active
2
–
Avance qui a été programmée avec M128
Palpeur à commutation, 350
10
–
Axe du palpeur
11
–
Rayon effectif bille
12
–
Longueur effective
13
–
Rayon bague de réglage
14
1
Désaxage axe principal
2
Désaxage axe auxiliaire
15
–
Sens du désaxage par rapport à la position 0°
1
