Chapter 1 : INTRODUCTION
1-1. SUPPLIED EQUIPMENT
• 1 Di-VentiX ™ .
• 1 AC power supply cord.
• 1 CD-ROM (Remote Control Software).
• 1 User’s Manual.
Supplied equipment with the OPT-iX-A option:
• 1 set of 11 MCO (5-pin) female connector (for audio connection).
1-2. GENERAL INFORMATION
Di-VentiX by Analog Way is a Full Digital Computer and Video Up/Down Mixer Scaler Switcher . In addition to
numerous effects such as fade, wipes, moving PIP and a true 8x2 scaled Matrix , Di-VentiX also includes a stand alone
Soft Edge function on to 2 projectors.
STAND ALONE EDGE BLENDING MODE: In Edge Blending mode, Di-VentiX can drive 2 video-projectors for
horizontal or vertical Soft Edge. Used as an 8 input switcher, Di-VentiX provides a double PIP image on a fixed
background thanks to the 6 full frame images stored in its non volatile memory. The background image can be chosen
among the 6 saved in the memory. The sources displayed in the PIPs can be switched.
MIXER MODE: Di-VentiX scales all sources and performs seamless switching transitions between any 2 inputs. The
2 Main outputs match the native resolution of any video-projector or hi-res. display device, and the Preview outputs
allow to monitor the sequences before they are displayed on the main screens to avoid errors during a presentation.
- PIP Effect: high quality picture insertion from any input. The PIP can be sized and moved anywhere over the
background image. Both background image and PIP can be fast & smoothly switched through a fade to black or
customized color. Customizable borders are also available as well as different opening modes: cut, fade, sliding from
one image Edge.
- FADE Effect: between any input, computer or video with adjustable cross-fading duration.
- TITLE Effect: over a Computer or a Video image. The title remains on the screen during the transition. The shadow
title function, with settable vertical size and position as well as level of shadow, increases readability on bright images.
- CUT & WIPES: Seamless switching between any 2 inputs and numerous horizontal and vertical wipe transitions.
NATIVE MATRIX MODE : Di-VentiX switches any of the 8 inputs to 1 of the 2 or both outputs. Inputs are scaled
and can be displayed with different resolutions on output 1 and 2.
COMMON FEATURES : Equipped with 2 SD/HD-SDI and 1 DVI input and DVI and HD-SDI outputs, Di-VentiX is
a full digital In/Out signal processor providing enhanced image quality. Di-VentiX features 3:2 and 2:2 pull down
circuitry, auto-adaptative pixel by pixel 3D motion compensation, time base corrector and frame rate converter &
follower. Each input image control can be individually set and stored in a non-volatile memory.
LOGO INSERTION & FRAME STORES : Record 6 full screen images and 8 logos in 16 million colors in a non-
volatile memory. Images and logo(s) can be flash captured from any video or computer source by keying or image cut-
out. Up to 2 logos can be allocated per input and positioned anywhere on the screen.
AUDIO OPTION: This optional card features 8 balanced stereo inputs, 2 balanced stereo outputs (+mono), 1 auxiliary
input mixed (not switched) with the 8 inputs with settable levels and master volume.
MULTIPLE SCREEN: Di-VentiX can be upgraded with Cross Blender for multiple edge blended screens.
Di-VentiX is specifically designed with a full control front panel for hi-res. A/V presentation displays, large events,
and for the rental and installation markets. It offers a user-friendly interface and can be easily controlled & upgraded
via its RS232, TCP/IP or by using the optional remote keypad.
