Chapter 6 : Di-VentiX & REMOTE KEYPAD SCREEN DESCRIPTION (continued) Di-VentiX™
PAGE 54
6-5. FRONT PANEL SCREEN FUNCTIONS DESCRIPTION (continued)
3[OUTPUT] + ENTER.
3-1 [output format] + ENTER.
Select one of the following output formats with  + ENTER.
• [848x480]
• [1400x1050]
• [800x600] • [1080p 16/9]
• [1280x720 16/9] • [1600x1200]
• [1024x768] • [720p HDSDI]
• [1280x768 16/9] • [1080i HDSDI]
• [1365x768] • [1080sf HDSDI]
• [1280x1024] • [1080p HDSDI]
• [1365x1024]
NOTE: For fixed pixels display devices (DMD, LCD, PLASMA…), always select the output format
corresponding to the native resolution of the display device. Thus, the display device will not have to
scale the image and the result will be better.
3-2 [output rate] + ENTER.
Select an output rate between:
• [internal 50Hz]: The output frame is generated at 50 Hz by the device.
• [internal 60Hz]: The output frame is generated at 60 Hz by the device.
• [internal 72Hz]: The output frame is generated at 72 Hz by the device.
• [internal 75Hz]: The output frame is generated at 75 Hz by the device.
• [follow]:
The output frame is synchronized onto one input signal. Select the needed input with
and validate with ENTER.
3-3 [output sync] + ENTER.
Select an output between MAIN & PREVIEW with  + ENTER.
Select the Output Sync. type with  + ENTER.
• [H&V]: H & V Sync.
• [COMP]: Composite Sync.
• [SOG]: Sync On Green.
3-4 [type of screen] + ENTER.
Select an item with  + ENTER.
• [4/3]: If your image is displayed on a 4/3 wall mounted projection screen shape.
• [16/9]: If your image is displayed on a 16/9 wall mounted projection screen shape.
NOTE: Available only in case of 4/3 output format.
3-5 [test pattern] + ENTER.
Select an output between MAIN & PREVIEW with  + ENTER.
Select an item with  + ENTER.
• [no pattern]: No test pattern is displayed.
• [centering]: Displays onto the output a centering pattern (for position and size adjustments).
• [color bar]: Displays onto the output a color bar pattern.
• [grid]: Displays onto the output a grid pattern.
• [H grey scale]: Displays onto the output a horizontal grey scale pattern.
• [burst]: Displays onto the output a multi-burst pattern.
• [softedge]: Displays onto the output a softedge pattern.
• [V grey scale]: Displays onto the output a vertical grey scale pattern.
