Chapter 3 : OPERATING MODE (continued) Di-VentiX™
PAGE 34
3-2. OPERATING WITH THE FRONT PANEL OF THE Di-VentiX (continued)
3-2-1. OPERATING IN MIXER MODE (continued)
• EXAMPLES OF TRANSITION
PIP effect:
The PIP effect allows to insert an image into another one.
• Press the PIP button, then do all the needed adjustments (duration, size, position...) with  and validate with
ENTER.
• Press the TAKE button to activate the effect (ACTION 1): the PREVIEW image is inserted into the MAIN
image.
NOTE:
• You can change the image in the PIP (PREVIEW image) by selecting another input of the PREVIEW
output (ACTION 2): Press the PREVIEW (OUTPUT SELECT) button and select the needed input (the
transition operates with a fading to black).
• You can change the background image (MAIN image) by selecting another input of the MAIN output
(ACTION 3): Press the MAIN (OUTPUT SELECT) button and select the needed input (the transition
operates with a fading to black).
• To remove the PIP effect, press the TAKE button.
• You can display the PIP source in is native resolution: set the horizontal & vertical size to 1:1 positions.
See Figure 21: PIP effect. Page 20.
Title effect (or shadow title):
The TITLE effect allows to display a text onto the MAIN image. For a better readability you also can display a
shadow bar onto your text.
• Create the text to be displayed with a computer using software such as PowerPoint®: the text should be bright
(yellow, white...) on a black background.
• Display on the MAIN output the source to titling, then pre-select the source used to display the text file create
above: the image appears on the PREVIEW output.
• Assign the TITLE effect to one of the USER buttons: Press one USER button, select title or shadow title with

and validate with ENTER, then select the duration with  and validate with ENTER.
• Press the TAKE button to activate the effect (ACTION 1): the text is now displayed onto the image of the MAIN
output.
NOTE: You can change the background image (MAIN image) by selecting another input of the MAIN output
(ACTION 2): Press the MAIN output select button and select the needed input (the transition operates with
a fading to black). To remove the TITLE effect, press the TAKE button (ACTION 3).
See Figure 22: Title effect. Page 21.
Wipe transition:
• Press a USER button, then assign a type of WIPE with the knob  and validate with ENTER (for example:
WIPE > hor wipe > from left), then select the duration with  and validate with ENTER.
• Press the TAKE button to activate the transition: the PREVIEW image appears onto the MAIN display with a
wipe transition.
See Figure 23: Wipe transition. Page 22.
Slide transition:
• Press a USER button, then assign a type of SLIDE with the knob  and validate with ENTER (for example:
Slide > from left), then select the duration with  and validate with ENTER.
• Press the TAKE button to activate the transition: the PREVIEW image appears onto the MAIN display with a
slide transition.
See Figure 24: Slide transition. Page 22.
