Di-VentiX™ APPENDIX A / ANNEXE A
PAGE 139
COMMAND RESPONSE
COMMAND DESCRIPTION VALUE /VALEUR
COMMANDE RÉPONSE DESCRIPTION DE LA COMMANDE
TYPE
MIN MAX DESCRIPTION
STATUS COMMANDS / COMMANDES D'ÉTAT
U UNIT Measures unity in tens of kHz. Rd 0 65535 ex: 14500 = 145 MHz
IL ILD Horizontal period of input signal (M) Rd 0 65535 Line frequency (in kHz) = (UNIT VALUE)x10
÷ (ILD VALUE).
il ild Horizontal period of input signal (P) Rd 0 65535 Line frequency (in kHz) = (UNIT VALUE)x10
÷ (ild VALUE).
ID IFD Vertical period of input signal (M) Rd 0 65535 Frame frequency (in Hz) = (Line frequency in
Hz) ÷ (IFD VALUE).
id ifd Vertical period of input signal (P) Rd 0 65535 Frame frequency (in Hz) = (Line frequency in
Hz) ÷ (ifd VALUE).
IP IPS Input Sync. detection (M). Rd 0 1 0 = no Sync. detected 1 = Sync. detected.
ip ips Input Sync. detection (P). Rd 0 1 0 = no Sync. detected 1 = Sync. detected.
IH IHP Sign of the horizontal input Sync. (M) Rd 0 1 0 = negative 1 = positive.
ih ihp Sign of the horizontal input Sync. (P) Rd 0 1 0 = negative 1 = positive.
IV IVP Sign of the vertical input Sync. (M) Rd 0 1 0 = negative 1 = positive.
iv ivp Sign of the vertical input Sync. (P) Rd 0 1 0 = negative 1 = positive.
IK IST Input Sync type detection (M). Rd 0 3
ik ist Input Sync type detection (P). Rd 0 3
0 = Separate H &V sync.
1 = Composite sync. (TTL).
2 = SOG (Sync. On Green).
3 = Composite sync. (analog).
II IIN Interlaced signal detection (M). Rd 0 1 0 = not interlaced 1 = interlaced.
ii iin Interlaced signal detection (P). Rd 0 1 0 = not interlaced 1 = interlaced.
IO IOO "Out of range" signal detection (M). Rd 0 1 0 = In range 1 = Out of range.
io ioo "Out of range" signal detection (P). Rd 0 1 0 = In range 1 = Out of range.
IF IFA Standard input signal detection (M). Rd 0 40
if ifa Standard input signal detection (P). Rd 0 40
0 = no signal 1 = wrong signal
2 = NTSC std (3.58/60) 3 = PAL std (4.43/50)
4 = SECAM (50Hz)
5 = B&W (50Hz)
6 = B&W (60Hz) 7 = YUV 50Hz
8 = YUV 60Hz 9 = RGB 50Hz
10 = RGB 60Hz 11 = VGA1 350L
12 = VGA2 400L 13 = VGA3 480L
14 = PLASMA 42" 15 = SVGA
16 = MAC 17 = XGA
18 = PLASMA 50' 19 = MAC 21'
20 = SXGA 21 = UXGA
22 = SXGA+ 23 = DILA 4/3
24 = DILA16/9 25 = 1080i 50Hz
26 = 1080i 60Hz 27 = 480p 60Hz
28 = 720p 50Hz 29 = 720p 60Hz
30 = 1080sf24 31 = 480p 50Hz
32 = 480p 72Hz 33 = 480p 75Hz
34 = WSXGA 35 =1080p 50Hz
36 = 1080p 60Hz 37 = 1080p 24Hz
38 = 1080p 25Hz 39 = 1080p 30Hz
40 = 1080sf 25Hz
XA REFA Synchronized input (M). Rd 0 8
xa refa Synchronized input (P). Rd 0 8
Identical as XR command.
XF REFF Synchronized input standard (M). Rd 0 29
xf reff Synchronized input standard (P). Rd 0 29
Identical as IF command.
XT REFT Frame frequency of the synchronized
input (M). Rd 0 65535 Value in hundredth of Hz.
xt reft Frame frequency of the synchronized
input (P). Rd 0 65535 Value in hundredth of Hz.
NOTE: (M) = MAIN output (sortie MAIN). Rd/Wr = Read and write command / Commande de lecture et d'écriture.
(P) = PREVIEW output (sortie PREVIEW). Rd = Read only command / Commande de lecture uniquement.
