Chapter 3 : OPERATING MODE (continued) Di-VentiX™
PAGE 42
3-3. OPERATING WITH THE REMOTE KEYPAD (continued)
3-3-3. OPERATING IN MATRIX MODE (continued)
• IMAGE ADJUSTMENTS
For each input source connected to the Di-VentiX do the following adjustments:
Select the source you want to adjust.
Select the aspect ratio of your input source with the screen menu (IMAGE > aspect ratio).
Use the Centering function (IMAGE > centering) to automatically position the image in the Centering
pattern.
IMPORTANT: For best results, display a full size bright image (no black border) to perform a centering. As
required, correct the adjustment the position & size with the IMAGE POS/SIZE button or with
the screen menu (IMAGE > pos settings).
NOTE: The centering function is only available for computer sources.
NOTE: In case of same Input/Output resolution, the centering also achieves automatic pixel clock adjustments. It
may be useful, to improve manually the pixel clock and phase using the screen menu (IMAGE > optimize
> clock or phase).
If needed, do the others adjustments, available in the screen IMAGE menu (color, brightness…).
NOTE: To set the image adjustments to the factory settings, use the Preset function (IMAGE > preset > yes).
NOTE: The adjustments are automatically stored in NON-volatile memories. The Di-VentiX is provided with 40
NON-volatile image memories. Each of these memories contains the input channel number, the input and
output format parameters and all of the image adjustments (position, size, brightness...). When the 40
memories are used, each new memorization erases the oldest record.
• AUDIO ADJUSTMENTS
For each AUDIO output, do the following adjustment.
Adjust the master volume (AUDIO xxxx > master volume).
Select the mono or stereo audio mode (AUDIO xxxx > audio mode > mono or stereo)
Select the auto follow or breakaway audio mode (AUDIO > audio source > auto follow or input # x):
- auto follow = the audio switching follows automatically the video switching.
- breakaway = the selected audio input is permanently diffused.
For each audio input, adjust the level (AUDIO xxxx > audio level) and the balance (AUDIO xxxx > audio
balance).
IMPORTANT: If the auxiliary audio input (AUX) is used, don't forget to activate it with the screen menu
(AUDIO xxxx > AUX input > ON).
