Chapter 6 : Di-VentiX & REMOTE KEYPAD SCREEN DESCRIPTION (continued) Di-VentiX™
PAGE 56
6-5. FRONT PANEL SCREEN FUNCTIONS DESCRIPTION (continued)
5 [LOGOS/FRAME] + ENTER
5-1 [use logo/frame] + ENTER.
Select an item with  + ENTER.
5-1-1 [display] + ENTER.
This function allows to display ON or OFF the assigned logos of the displayed input. Select an input and
press ENTER to display ON or OFF.
NOTE: To display a logo or a frame, the output format should be the same that the output format used
during the storing.
5-1-2 [assignment] + ENTER.
This function allows assigning the stored frame and the logos to the inputs of the device (up to 2 logos at
the same time).
Select MAIN or PREVIEW displayed input with  + ENTER.
Select the frame index or the logo index 1 or the logo index 2 with  + ENTER.
Then select a logo, a frame or none with  + ENTER.
Adjust the logo position with H & V position functions.
NOTE: To assign the same logo to all inputs, select ALL in the step .
5-1-3 [fade duration] + ENTER.
This function allows adjusting the fade duration of the logo when you display ON or OFF a logo. Adjust
the duration with  and validate with ENTER.
5-1-4 [transparency] + ENTER.
This function allows adjusting the transparency of the logo. Select a logo, adjust with  and validate
with ENTER.
5-2 [record logo] + ENTER.
This mode allows storing up to 8 logos in order to incrust them into the displayed image (up to 2 logos at a same
time). Select an item with  + ENTER.
5-2-1 [H position] + ENTER.
Adjust the Horizontal position of the logo area with  + ENTER.
5-2-2 [V position] + ENTER.
Adjust the Vertical position of the logo area with  + ENTER.
5-2-3 [H size] + ENTER.
Adjust the Horizontal size of the logo area with  + ENTER.
5-2-4 [V size] + ENTER.
Adjust the Vertical size of the logo area with  + ENTER.
NOTE: The logo area is limited at an eighth (1/8) of the displayed area.
5-2-5 [luma key level] + ENTER.
This function allows to "erasing" the darkest portions of your logo area in order to make special logo
contour. Adjust the luma key level with  + ENTER.
5-2-6 [back. color] + ENTER.
This function allows coloring the "erased portions" of the logo when using the luma key. Select a level
with  + ENTER.
5-2-7 [store] + ENTER.
This function allows storing the logo into one of the 8 logo memories. Select a logo memory with  +
ENTER. The memorization will take few seconds.
