Di-VentiX™ APPENDIX A / ANNEXE A
PAGE 135
COMMAND RESPONSE
COMMAND DESCRIPTION VALUE /VALEUR
COMMANDE RÉPONSE DESCRIPTION DE LA COMMANDE
TYPE
MIN MAX DESCRIPTION
EFFECTS COMMANDS / COMMANDES D'EFFET
E EFF Effect selection. Rd/Wr 0 14 0 = CUT. 1 = FADING.
2 = TITLE. 3 = shadow TITLE
4 = PIP. 5 = PIP fade.
6 = from left. 7 = from right.
8 = to center H. 9 = from center H.
10 = Up. 11 = Down.
12 = to center V. 13 = from center V.
14 = Double PIP.
eD EFD Effect duration selection. Rd/Wr 5 255 5 = 0.5 second 244 = 24.5 seconds
255 = holding
ea EFPA Horizontal position of the effect. Rd/Wr 0 255
eb EFPB Vertical position of the effect (PIP...) Rd/Wr 0 255
ec EFPC Horizontal size of the effect (PIP...) Rd/Wr 0 255 0 = PIP 1:1 5 = size mini 255 = size maxi
ed EFPD Vertical size of the effect (PIP). Rd/Wr 0 255 0 = PIP 1:1 5 = size mini 255 = size maxi
ee EFPE Hor. shape position (PIP). Rd/Wr 0 255
ef EFPF Vertical shape position (PIP). Rd/Wr 0 255
eg EFPG Horizontal shape size (PIP). Rd/Wr 0 255
eh EFPH Vertical shape size (PIP). Rd/Wr 0 255
eO EFO Effect options Rd/Wr 0 5 0 = without 2 = smooth
1 = shadow 3 = edge
4 = active Inlay when double PIP.
5 = smooth edge
ei EFPI Border size or frame selection for
double PIP.
Rd/Wr 0 255
• If double PIP:
0 = frame 1............
5 = frame 6
• If PIP:
0 = size mini
255 = size maxi.
ej EFPJ -Intensity of the shadow borders (if
EFF = 4 & EFO = 1).
-Color of the edge & smooth edge
borders (if EFF = 4 & EFO = 3 or 5).
- Preview Opacity in double PIP (if
EFF =14).
Rd/Wr 0 255
us EFPS Color of the shadow borders. Rd/Wr 0 255
eu EFOP Effect opening type. Rd/Wr 0 15
ev EFCL Effect closing type. Rd/Wr 0 15
0 = Cut 1 = fade
2 = slide Left-Right 3 = slide Right-Left
4 = slide Bottom-Up 5 = slide Up-Bottom
6 = wipe Left-Right 7 = wipe Right-Left
8 = wipe H to center 9 = wipe V to center
10 = wipe Bottom-Up 11 = wipe Up-Bottom
12 = wipe V to center 13 = wipe V from center
14 = wipe H&V to center
15 = wipe H&V from center
es EFPT Effect opening duration (0.1 sec step) Rd/Wr 0 255
et EFCT Effect closing duration (0.1 sec step) Rd/Wr 0 255
uk EFPK Horizontal position of the main PIP. Rd/Wr 0 255
ul EFPL Vertical position of the main PIP. Rd/Wr 0 255
um EFPM Horizontal size of the main PIP. Rd/Wr 0 255 0 = PIP 1:1 5 = size mini 255 = size maxi
un EFPN Vertical size of the main PIP. Rd/Wr 0 255 0 = PIP 1:1 5 = size mini 255 = size maxi
uo EFPO Horizontal mask position of the main
PIP.
Rd/Wr 0 255
up EFPP Vertical mask position of the main PIP. Rd/Wr 0 255
uq EFPQ Horizontal mask size of the main PIP. Rd/Wr 0 255
Dou
bl
e PI
P effect
ur EFPR Vertical mask size of the main PIP. Rd/Wr 0 255
g EON Effect in progress. Rd 0 1 0 = no effect in progress.
1 = effect in progress.
NOTE: (M) = MAIN output (sortie MAIN). Rd/Wr = Read and write command / Commande de lecture et d'écriture.
(P) = PREVIEW output (sortie PREVIEW). Rd = Read only command / Commande de lecture uniquement.
