Chapter 7 : TECHNICAL SPECIFICATIONS (continued)
Di-VentiX™
PAGE 66
7-2. MAIN & PREVIEW OUTPUTS
• HD-SDI OUTPUTS
Connector:
BNC female.
Formats:
720p @ 50 & 59.94 Hz
1080i @ 50 & 59.94 Hz
1080p @ 23.97; 25 & 29.97 Hz.
1080sF @ 23.97 & 25 Hz.
Data rate:
1.5 Gbps serial digital.
Impedance: 75
ohms.
• ANALOG OUTPUTS
Connector:
HD15 female.
Signals:
RGBHV, RGBS and RGsB.
Resolutions:
4/3: SVGA (800x600), XGA (1024x768), SXGA (1280x1024), D-ILA (1365x1024),
SXGA+ (1400x1050) and UXGA (1600x1200).
16/9: 848x480, 1280x720, 1280x768, 1365x768, 1920x1080.
Frame rates:
50, 60, 72 and 75 Hz (72 & 75 Hz frame rates are not available for all resolutions. Please
see the table below).
Levels:
R, G, B = 0.7 Vp/p.
Sync.: Separate H & V = TTL.
Composite = TTL.
SOG = 0.3 Vp/p.
Impedance:
R, G, B = 75 ohms.
• DIGITAL COMPUTER (DVI) OUTPUTS
Connector:
DVI-I female.
Signal:
Digital Visual Interface (DVI)-TMDS single link.
Resolutions:
4/3: SVGA (800x600), XGA (1024x768), SXGA (1280x1024), D-ILA (1365x1024),
SXGA+ (1400x1050) and UXGA (1600x1200).
16/9: 848x480, 1280x720, 1280x768, 1365x768, 1920x1080.
Frame rates:
50, 60, 72 and 75 Hz (72 & 75 Hz frame rates are not available for all resolutions. Please
see the table below).
• OUTPUT FORMATS TABLE
Resolution
Frame rate
HD15
DVI-D
BNC
848x480
50,60,72,75,F
3
3
800x600
50,60,72,75,F
3
3
1280x720
50,60,F
3
3
1024x768
50,60,72,75,F
3
3
1280x768
50,60,72,75,F
3
3
1365x768
50,60,72,75,F
3
3
1280x1024
50,60,72,75,F
3
3
1365x1024
50,60,72,75,F
3
3
1400x1050
50,60,72*,75*,F
3
3
1920x1080
50,59
3
3
1600x1200
50, 60*
3
3
720p HD-SDI
50,59
3
1080i HD-SDI
50,59
3
1080sf HD-SDI 24,25
3
1080p HD-SDI 24,25,29
3
Outputs formats
Outputs connectors
* = Reduced blanking
F = follow mode
