Di-VentiX™ Chapter 6 : Di-VentiX & REMOTE KEYPAD SCREEN DESCRIPTION (continued)
PAGE 57
6-5. FRONT PANEL SCREEN FUNCTIONS DESCRIPTION (continued)
5-3 [record frame] + ENTER.
This mode allows storing a frame in order to display them at any time during the show.
5-3-1 [H position] + ENTER.
Adjust the Horizontal position of the frame area with  + ENTER.
5-3-2 [V position] + ENTER.
Adjust the Vertical position of the frame area with  + ENTER.
5-3-3 [H size] + ENTER.
Adjust the Horizontal size of the frame area with  + ENTER.
5-3-4 [V size] + ENTER.
Adjust the Vertical size of the frame area with  + ENTER.
5-3-5 [luma key level] + ENTER.
This function allows to "erasing" the darkest portions of your frame area in order to make special logo
contour. Adjust the luma key level with  + ENTER.
5-3-6 [back. color] + ENTER.
This function allows coloring the "erased portions" of the frame when using the luma key. Select a level
with  + ENTER.
5-3-7 [store]
This function allows storing the frame into one of the 6 frame memories. Select a frame memory with
+ ENTER. The memorization will take about 2 minutes.
5-4 [erase mode] + ENTER.
This function allows erasing the memorized frame and/or the logos. Select an item with  + ENTER.
6[EFFECT]
This menu allows to store an effect in each of the effect buttons (USER buttons).
6-1 [current effect]
The front panel screen displays the current effect.
First select an effect button with  + ENTER between:
6-2 [USER 1 key]
6-3 [USER 2 key]
6-4 [USER 3 key]
6-5 [USER 4 key]
Then select one of the following effects:
6-x-1 [cut]: allows to switch seamlessly the pre-selected input onto the MAIN output.
NOTE: The opening & closing animation available with this effect is: CUT.
6-x-2 [fading]: allows to fade the pre-selected input to the MAIN output. You can select the duration of the
transition as indicated below:
• [1s]: 1 second transition.
• [3s]: 3 seconds transition.
• [5s]: 5 seconds transition.
• [custom]: Select a duration from 0.5 second up to 25 seconds by 0.5 second steps.
NOTE: The opening & closing animation available with this effect is: FADE.
6-x-3 [title]: Allows to overlay a title on the MAIN output. The title should be done with drawn standard
software (Paint, PowerPoint...) in white color on a black background. You can select the duration of this
effect between:
• [holding]: The text appears after pushing on the TAKE button, and will be removed only by a second
push on the TAKE button.
• [3s]: 3 seconds transition.
• [5s]: 5 seconds transition.
• [custom]: Select a duration from 0.5 second up to 25 seconds by 0.5 second steps.
NOTE: The opening & closing animations available with this effect are: CUT, FADE, Horizontal slides.
