Chapter 3 - OCP 42/OCP 50 Maintenance 185
Access to the various units
THOMSON OCP 42/OCP 50
User manual
B1500M24LA
September 2000
WARNING
ALL COMPONENTS MUST BE REPLACED BY THOMSON BROADCAST
SYSTEMS ORIGINAL COMPONENTS
3.1 - ACCESS TO THE VARIOUS UNITS
3.1.1 - Removing the cover
• Loosen the 6 cover attaching screws and the monocontrol mechanism attaching screw.
• Remove the cover.
Pay attention to the connector J12 on the MPU BOARD connected to the DC IN
(XLR4) connector coupled to the cover.
Control knob with its bottom ring
Bottom part
Screw
Ring
Groove
Control knob without bottom ring
