172 Chapter 2 -OCP 42/OCP 50 Operating Instructions
OCP 42/OCP 50 memory card & memory key
B1500M24LA
September 2000
THOMSON OCP 42/OCP 50
User manual
NOTE: For change a card configured as a ‘STUDIO’ card into a ‘CAMERA’ card or
vice-versa, the memory card datas must be erased "(PRESET+ERASE CARD)":
2.7.1.3 - Operating configurations
2.7.1.3.1 - Configuring a camera with a CCU
Note: The OCP 42 may be replaced by the OCP 50: only the IRIS control is different. The
OCP50 is not fitted of PREVIEW control.
Record and read the camera’s technical values and operating settings with a
‘CAMERA’ card.
Record and read the camera’s operating settings with a ‘STUDIO’ card.
Record and read the technical values and operating settings for the camera selected
using the MSP with a ‘CAMERA’ card.
D E T A I L KN E E
SAT URA T I ON P E D E S T A L
FLAR E RGB COR I NG
GAMMA L E V E L D E P
S K I N 1 S K I N 2
ERAS E CARD PRESET
(OCP key)
NEXT
(OCP key)
NEXT
(OCP key)
OCP 42
OCP 50
1
2
3
4
5
MSP
16
17
18
19
20
21
22
23
24
6
7
8
9
10
11
CAM 11 - 15
12
13
14
15
CAMERA
1657D/1657*/1557D
CCU 1685/1686
OCP 42
2
1
OCP 42
CAMERA
1657D/1657*/1557D
CCU 1685/1686
OCP 42
2
1
OCP 42
CAMERA
1707*
DT 500
OCP 42
2
1
MSP OCP 50
MCP
TO OTHER CCUS
