174 Chapter 2 -OCP 42/OCP 50 Operating Instructions
OCP 42/OCP 50 memory card & memory key
B1500M24LA
September 2000
THOMSON OCP 42/OCP 50
User manual
2.7.2 - Operation
2.7.2.1 - General
A ‘STUDIO’ card can be used to store operating settings and ‘SCENE FILES’ for a set of
cameras (up to 24).
A ‘CAMERA’ card can be used to store operating settings, ‘SCENE FILES’ and technical
values for a single camera.
2.7.2.2 - ‘Studio to card’ transfer
In general terms, this function is used to store operating settings for a set of cameras (OCP
50+MSP) or for a camera (OCP 42) on the card.
Pressing the MEMORY key on the panel (OCP42/OCP 50) brings up the main transfer
STUDIO page:
With the main transfer page displayed, pressing the STORE key brings up the following
display:
The following functions are available on this page:
• TFR TYPE: indicates the type of settings to be transferred. Cannot be modified.
- OP + SF: transfer all the operating settings and the 4 ‘Scene Files’
The Paragraph Settings and values transferred, listed by type 2.7.3 -describes in detail the
settings transferred.
• CARD FILE: indicates the type of card present in the card reader. Cannot be modified.
- STUDIO: studio card.
- NO STUDIO: camera card or unknown type (not possible to write to the card).
- NO CARD: no card present in the card reader.
- NO FILE: blank card.
• WRITE CARD: selecting this function using the corresponding operating key has the
following effect:
- With an OCP 50+MSP: saves on the card all the operating settings and the 4 ‘Scene Files’
for all the cameras connected to the MCP.
- With an OCP 42: saves on the card all the operating settings and the 4 ‘Scene Files’ for
the camera connected to the CCU. The settings for up to 24 cameras can be stored on one
card. These cameras must have a different number defined in the SETTINGS on the
R E CA L L S T OR E
S T UD I O CARD
R E CA L L S T OR E
S T UD I O CARD
T F R T Y P E CARD F I L E
OP + S F X X X X
ABOR T WR I T E CARD
