Chapter 2 - OCP 42/OCP 50 Operating Instructions 169
Description of rest pages
THOMSON OCP 42/OCP 50
User manual
B1500M24LA
September 2000
The following status is permanently displayed:
• Indication 2/2 indicates that the page displayed is the 2nd status page.
Figure 3 : Rest STATUS 2 page
2.6.3 - REST-VALUE page
This page display:
1. By pressing the NEXT key:
• If the page displayed is the STATUS 1 page and there is no STATUS 2 page.
• If the STATUS 2 page is displayed.
2. If the REST TIME adjustment is on 3 SEC. (refer to INSTALLATION chapter, 1.7.3
- Setting up the OCP paragraph), a modification of one of the following values causes
timed display of this page:
• R, B partial gains.
• R, G, B partial blacks.
The following states are permanently displayed:
• R and G partial gains.
• R, G, B partial blacks.
• Detail value.
• MASTER PED value.
• SATURATION value.
• Iris aperture.
Figure 4 : Rest VALUE page
Note: In this configuration, only the «SAT» (saturation) cannot be modified.
