Chapter 2 - OCP 42/OCP 50 Operating Instructions 135
General
THOMSON OCP 42/OCP 50
User manual
B1500M24LA
September 2000
2.1 - GENERAL
The panel is operated by means of:
1. PUSHBUTTONS
• Operational pushbuttons:
- Buttons (4) located around the display.
- Buttons: NEXT, EXIT, WHITE BAL, BLACK BAL.
• Control buttons:
- LOCK, ACTIV, CCU STATUS, BARS, CALL, ENABLE, PRESET, AUTO IRIS,
STORE, RECALL.
• Range buttons:
- GAIN, filters, detail, dfz, black, colour, knee, shutter, gamma, SKIN, fine adjust, setting.
Note: The SETTING button is described in the Installation chapter of this manual.
• Programmable buttons:
- F1, F2, F3, F4.
• Memory button:
- MEMORY
2. LINEAR CONTROLS
• Partial R, G, B gain controls (also used for some other adjustments).
• IRIS setting control.
• R, G, B partial black controls (also used for other adjustments).
• MASTER PED control (located on end of joystick OCP 40/OCP 42).
• ADJUST control, assigned according to the settings to modification of different parameters.
3. INDICATOR LIGHTS
• ON AIR 1 indicator light
• ON AIR 2 indicator light
• EXTENDER indicator light
• PREVIEW indicator light
• CTRL indicator light
• DIAG indicator light
• ASSIGNED indicator lights
• LIMIT (WHITE BAL) indicator light
• LIMIT (BLACK BAL) indicator light.
4. A DISPLAY
The display displays one of the following:
• The range page selected by a range button.
• The status reset pages.
• The value rest page.
• The settings pages.
