Chapter 2 - OCP 42/OCP 50 Operating Instructions 175
OCP 42/OCP 50 memory card & memory key
THOMSON OCP 42/OCP 50
User manual
B1500M24LA
September 2000
corresponding OCP (refer to the INSTALLATION section of this manual).
The Paragraph Settings and values transferred, listed by type 2.7.3 -describes in detail the
settings transferred.
During the writing, the following page displays:
• ABORT: selecting this function using the corresponding operating key returns you to the
previous page.
2.7.2.3 - ‘Card to studio’ transfer
In general terms, this function is used to read the operating settings for a set of cameras
(OCP50+MSP) or for a camera (OCP 42) from the card and to transfer them to a set of cameras
or for a camera.
Pressing the MEMORY key on the panel (OCP42/OCP 50) brings up the main transfer
STUDIO page:
With the main transfer page displayed, pressing the RECALL key brings up the following
display:
The following functions are available on this page:
• TFR TYPE: indicates the type of settings to be transferred. Cannot be modified.
- OP + SF: transfer all the operating settings and the 4 ‘Scene Files’
The Paragraph Settings and values transferred, listed by type 2.7.3 -describes in detail the
settings transferred..
• CARD FILE: selects the source files.
- STUDIO:
- With an OCP 50: the settings for all the cameras stored (1 to 24) will be transferred to the
cameras with the same numbers connected to the MSP. In this mode, the ALL and GROUP
keys on the MSP are inactive.
- With an OCP 42: this selection is not authorised.
WR I T I NG CARD
I N P ROGR E S S . . . .
P l e a s e w a i t
R E CA L L S T OR E
S T UD I O CARD
R E CA L L S T OR E
S T UD I O CARD
T F R T Y P E CARD F I L E
x x x x x x x x
ABOR T WR I T E CAM
