122 Chapter 1 - OCP 42/OCP 50 Installation
Setting up
B1500M24LA
September 2000
THOMSON OCP 42/OCP 50
User manual
purposes.Refer to the MAINTENANCE chapter, 3.2.2 - Calibration of iris control (OCP 42)
paragraph.
• CONTRAST: Display contrast adjustment.
• LED TEST: Pressing this button light all the OCP leds (except "PREVIEW) during 3
seconds.
Operation of the NEXT button displays panel setting up page 5:
This page indicate:
• KEYB: "SOFT" version "HC11" keyboard circuit.
• BOARD: "HARD" version "MPU BOARD" PCB.
• SPEED: OCP RS 422 link speed (KBAUDS).
OC P S T A T U S
KEY B : X . X X
BOARD : X
SPE E D : X X X X
