N 77 M105
N 78 T1 [// Finition - contour 10mm - externe - face frontale ]
N 79 G17
N 80 G197 S637 G193 F0.1 M103
N 81 G0 X8 Z3
N 82 G0 Y0
N 83 G147 I2 K2
N 84 G845 NS15 P3 I1 U0.5 V0.5 H1 Q0
N 85 G0 X8 Z3
N 86 G0 Y0
N 87 G0 X220 Z400
N 88 M105
N 89 T5 [// Fraisage - figure libre - externe - surface
enveloppe]
N 90 G19
N 91 G197 S637 G193 F0.1 M103
N 92 G0 X106 Z-50
N 93 G0 Y11
N 94 G147 I2 K2
N 95 G845 NS23 P1 U0.5 V0.5 H1 Q0
N 96 G0 X106 Z-50
N 97 G0 Y0
N 98 G0 X140 Z500
N 99 M105
N 100 G0 Y0
N 101 G18
N 102 M15
N 103 M30
