170
Cycles d'usinage : fraisage de poches / tenons / rainures
5.8 Ex
emples de pr
ogr
a
mmation
Q248=90
;ANGLE D'OUVERTURE
Q378=180
;INCRÉMENT ANGULAIRE
Point initial 2ème rainure
Q377=2
;NOMBRE D'USINAGES
Q207=500
;AVANCE FRAISAGE
Q351=+1
;MODE FRAISAGE
Q201=-20
;PROFONDEUR
Q202=5
;PROFONDEUR DE PASSE
Q369=0.1
;SUREP. DE PROFONDEUR
Q206=150
;AVANCE PLONGEE PROF.
Q338=5
;PASSE DE FINITION
Q200=2
;DISTANCE D'APPROCHE
Q203=+0
;COORD. SURFACE PIÈCE
Q204=50
;SAUT DE BRIDE
Q366=1
;PLONGEE
Q439=0
;REFERENCE AVANCE
14 CYCL CALL FMAX M3
Appel du cycle Rainure
15 L Z+250 R0 FMAX M2
Dégager l'outil, fin du programme
16 END PGM C210 MM
