TNC 410, TNC 426, TNC 430 HEIDENHAIN
441
13.2 Distr
ibution des plots et c
â
bles de r
a
ccor
d
ement pour les
int
erf
aces
de
donn
é
es
Prise femelle RJ45 pour Interface Ethernet
(option, sauf TNC 410)
Longueur câble max.:non blindé: 100 m
blindé: 400 m
Prise femelle BNC pour Interface Ethernet
(option, sauf TNC 410)
Longueur câble max.: 180 m
Plot
Signal
Description
1
TX+
Transmit Data
2
TX–
Transmit Data
3
REC+
Receive Data
4
libre
5
libre
6
REC–
Receive Data
7
libre
8
libre
Plot
Signal
Description
1
Données (RXI, TXO)
Conducteur interne (âme)
2
GND
Blindage
