196 Chapter 6 - Rear adapter (CA25)
Connector definitions
B1657D902C
Septembre 2000
THOMSON TTV 1657D
User manual
6.3 - CONNECTOR DEFINITIONS
1 - VTR/CCU
Socket:
TYPE : SRC B 02A 21-26P
REF : 91.583.192
Plug:
TYPE : SRC B 06 A
REF : 91.592.584
2 - MICROPHONE
INPUT
Socket:
TYPE : XLRNCF30-V
Level: - 60 dB
Phantom supply:
+ 9 V
3 - INCOM HEAD
SET
Socket:
TYPE : TUCHEL 2121
Plug:
REF : T2121000
4 - POWER DC IN
Socket:
TYPE : XLR 4-32F515-01
)
*
!
"
# $
%
&
'
!
"
#
$
%
&
'
!
"
1
2
3
4
7
6
5
8
13
12
11
10
9
16
15
14
17
22
21
20
19
18
A
24
23
B
ENCODED VIDEO
ENCODED VIDEO GND
Y/G GND
Y/G VIDEO
R-Y/R VIDEO
R-Y/R GND
B-Y/B VIDEO
B-Y/B GND
MIC OUT X
MIC OUT Y
LONG CABLE/MIC GND
VTR ST ST OUT
BATT IND/DATA
ALIM CONT
REC TALLY
GEN.LOCK VIDEO GND
INCOM GND
PB VIDEO IN
PB VIDEO GND
AUDIO MONITOR/BTR SAVE
GEN.LOCK VIDEO IN
COLOUR FRAME OUT
INCOM.X
INCOM.Y
+12V POWER CABLE
GND (POWER)
!
!
0
1
2
3
4
5
6
(NC)
4
3
2
6
5
1
- MICRO
+ MICRO
GND MICRO
GND EAR
EAR LEFT
EAR RIGHT
!
"
ALIM
GND
(0V)
+ BATT
(11/17V=)
NC
1
2
3
4
J40
NC
