Grass Valley TTV 1657D - Manuel (Page 157)

Chapter 3 - Viewfinders 157
THOMSON TTV 1657D
User manual
B1657D902C
Septembre 2000
Chapter 3
Viewfinders
3.1 - 4 cm viewfinder ........................................................... 159
3.1.1 - Controls and functions ....................................................................... 159
3.1.2 - Indicator lights.................................................................................... 161
3.1.3 - Electrical settings............................................................................... 162
3.1.4 - Mechanical settings ........................................................................... 163
3.2 - 14 cm viewfinder ......................................................... 165
3.2.1 - Principal characteristics ..................................................................... 165
3.2.2 - Accessories ....................................................................................... 165
3.2.3 - General description............................................................................ 166
3.2.4 - Description of controls ....................................................................... 167
3.2.5 - Fitting of viewfinder on mounting ....................................................... 169
