Chapter 7 : TECHNICAL SPECIFICATIONS (continued) CENTRIX™ & EVENTIX™
PAGE 62
7-5. OPTIONAL AUDIO INPUTS (OPT-iX-A)
• 9 Balanced and unbalanced stereo inputs (on 5-pin MCO male connector).
• Vi = + 18 dBu (max).
• Zi = 20 kΩ unbalanced.
• Zi = 40 kΩ balanced.
7-6. OPTIONAL AUDIO OUTPUT (OPT-iX-A)
• 2 Balanced and unbalanced mono/stereo outputs (on 5-pin MCO male connector).
• Vo max:
Unbalanced = + 18 dBu (+12 dBu with 300Ω load).
Balanced = + 24 dBu (+18 dBu with 600Ω load).
• Zo = 600 Ω balanced.
• Zo = 300 Ω unbalanced.
• G = 0 dB nominal.
• G = + 6 dB / - ∞ adjustable with Master volume.
7-7. HDTV OUTPUTS (EVX8022HD-D model only)
• HD YUV OUTPUT
Connector:
DB9 female.
Levels: Y = 1 Vp/p (0.7 V + sync.).
R-Y = 1 Vp/p (0.7 V + sync.).
B-Y = 1 Vp/p (0.7 V + sync.).
Sync.: Tri-levels: ±0.3V (positive/negative).
Impedance: 75 ohms.
• HD SDI OUTPUT
Connector:
BNC female.
Data rate: 720p @ 59.94 or 60 Hz: 1.5 Gbps serial digital output conforming to SMPTE 296M.
1080i @ 59.94 or 50 or 60 Hz: 1.5 Gbps serial digital output conforming to SMPTE 274M.
1035i @ 59.94 Hz: 1.5 Gbps serial digital output conforming to BTA-S004B.
1035i @ 60 Hz: 1.5 Gbps serial digital output conforming to BTA- S001.
Impedance: 75 ohms.
7-8. ENVIRONMENTAL
Power Supply: Internal CE / UL / CSA / IEC 950 (130W).
Input : 100 VAC to 240 VAC ; 50-60Hz ; I = 3A Max.
Storage Temperature: -25 °C to +85 °C (-13 °F to +185 °F).
Operating temperature: 0 °C to 50 °C (32 °F to 122 °F).
Maximum ambient operating temperature: < 40 °C ( < 104 °F).
Hygrometry: 10% to 80% (without condensation).
Dimension: W 480 x D 420 x H 133 mm / 19”W x 16.5”D x 5.25”H.
(Compatible with a Standard 19” rack, Height = 3 U).
Weight: CTX8022: 7.5 kg / 16.5 lbs.
CTX8022-D: 8 kg / 17.6 lbs.
EVX8022: 8 kg / 17.6 lbs.
EVX8022-D: 8.5 kg / 18.7 lbs.
EVX8022HD-D: 9 kg / 19.8 lbs.
OPT-iX-SDTVD1: + 0.5 kg / 1.1 lbs.
OPT-iX-A: + 0.5 kg / 1.1 lbs.
