CENTRIX™ & EVENTIX™
PAGE 59
Chapter 7 : TECHNICAL SPECIFICATIONS
7-1. COMPUTER & VIDEO INPUTS
• ANALOG COMPUTER:
Connectors:
BNC female (inputs #1 to #4) or HD15 female (inputs #5 to #8).
Line frequency:
Up to 110 kHz.
Frame frequency:
Up to 130 Hz.
Resolution:
Up to 1600 x 1200 @ 60 Hz.
Sync. types:
RGBHV, RGB/S, RGsB (Sync On Green).
Levels:
R, G, B = 0.7 Vp/p.
H & V Sync = TTL
Composite Sync = TTL and 0.3 V.
SOG (Sync On Green) = 0.3 V.
Impedance:
R, G, B = 75 ohms.
H = 75 ohms or Hi-Z.
V = Hi-Z.
• RGB/S VIDEO:
Connectors:
BNC female (inputs #1 to #4) or HD15 female (inputs #5 to #8).
Frequency:
15.625 kHz - 50 Hz (625 lines).
15.735 kHz - 60 Hz (525 lines).
Levels:
R, G, B = 0.7 Vp/p.
SYNC. = 0.3 Vp/p or TTL.
Impedance:
RGB = 75 ohms.
SYNC. = 75 ohms or Hi-Z.
• COMPONENT:
Connectors:
BNC female (inputs #1 to #4) or HD15 female (inputs #5 to #8).
Frequency:
15.625 kHz - 50 Hz (625 lines).
15.735 kHz - 60 Hz (525 lines).
Levels:
Y = 1 Vp/p (0.7 V Luma + 0.3 V Sync.).
Cr / Pr & Cb / Pb = 0.7 Vp/p.
Impedance: 75
ohms.
• HDTV:
Connectors:
BNC female (inputs #1 to #4) or HD15 female (inputs #5 to #8).
Formats:
720p, 1035i, 1080i.
Levels:
Y = 1 Vp/p (0.7 V + sync.).
Cr / Pr & Cb / Pb = 1 Vp/p (0.7 V + sync.).
Sync.:
Tri-level: ±0.3V (positive/negative).
Bi-level: 0.3V (negative).
Impedance: 75
ohms.
• S.VIDEO:
Connectors:
BNC female (inputs #1 to #4) or HD15 female (inputs #5 to #8).
Standard:
PAL / SECAM: 15.625 kHz - 50 Hz - 625 lines.
NTSC (3.58 MHz / 4.43 MHz): 15.735 kHz - 60 Hz - 525 lines.
Levels:
Y = 1 Vp/p (0.7 V Luma + 0.3 V Sync.).
C = 0.3 Vp/p (Chroma Burst).
Impedance:
75 ohms.
