CENTRIX™ & EVENTIX™ Chapter 6 : EVENTIX™ & REMOTE KEYPAD LCD SCREEN DESCRIPTION (continued)
PAGE 49
6-5. LCD FUNCTIONS DESCRIPTION (continued)
3-3 [output sync] + ENTER.
c Select an output between MAIN & PREVIEW with  + ENTER.
d Select the Output Sync. type with  + ENTER.
• [H&V]: H & V Sync.
• [COMP]: Composite Sync. • [SOG]: Sync On Green.
3-4 [type of screen] + ENTER.
Select an item with  + ENTER.
• [4/3]: If your image is displayed on a 4/3 wall mounted projection screen shape.
• [16/9]: If your image is displayed on a 16/9 wall mounted projection screen shape.
NOTE: Available only in case of 4/3 output format.
3-5 [test pattern] + ENTER.
c Select an output between MAIN & PREVIEW with  + ENTER.
d Select an item with  + ENTER.
• [no pattern]: No test pattern is displayed.
• [centering]: Displays onto the output a centering pattern (for position and size adjustments).
• [color bar]: Displays onto the output a color bar pattern.
• [grid]: Displays onto the output a grid pattern.
• [grey scale]: Displays onto the output a grey scale pattern.
• [multi-burst]: Displays onto the output a multi-burst pattern.
• [softedge]: Displays onto the output a softedge pattern.
3-6 [video output] + ENTER. This menu is available with the OPT-iX-SDTVD1 option and on the EVX8022HD-D.
NOTE: The following functions act on the optional video outputs only (Composite video, S.VIDEO, YUV and SDI).
3-6-1 [video standard] + ENTER.
Select an output standard for the SDTV outputs with  + ENTER between:
• [NTSC]: NTSC for composite and S.VIDEO outputs. 60Hz frame rate for YUV & SDI outputs.
• [PAL]: PAL for composite and S.VIDEO outputs. 50Hz frame rate for YUV & SDI outputs.
• [NTSCj]: Japan NTSC for composite and S.VIDEO outputs. 60Hz frame rate for YUV & SDI outputs.
Or select an output format for the HDTV video outputs with  + ENTER between:
• [720p 59.94Hz]
• [1035i 59.94Hz] • [1080i 50Hz]
• [720p 60Hz] • [1035i 60Hz] • [1080i 59.94Hz]
• [1080i 60Hz]
3-6-2 [output rate] + ENTER.
Select a function with  + ENTER between:
• [internal]: The video output rate is generated by the device depending of the selected video standard.
• [input # X]: The video output rate is synchronized onto an input of your choice (video source only).
NOTE: If the device is already set in follow mode (LCD menu # 3-2 = follow...). This input and the
input used for the follow mode should be the same.
3-6-3 [flicker adj.] + ENTER.
Select a level of anti-flicker with  + ENTER.
3-6-4 [U/Over scan] + ENTER.
Select a function with  + ENTER between:
• [underscan]: The entire image is visible on the screen. Computer display mode is underscan.
• [overscan]: The image is displayed about 8 % bigger than in underscan mode, to avoid seeing the
corners and the borders. Standard TV display mode is overscan.
3-6-5 [pos settings] + ENTER.
Adjust the video image position with the following functions:
• [size]: Adjust the Horizontal & Vertical size with H and V knobs.
• [position]: Adjust the Horizontal & Vertical position with H and V knobs.
3-6-6 [input stab.] + ENTER.
This function allows improving the input stability of the referenced input. Select the type of the referenced
source between DVD & VCR.
3-6-7 [color tracking] + ENTER.
This function allows to improve the image color (act only if input stab. = VCR).
