FRAME & LOGOS COMMANDS / COMMANDES DU MENU LOGO & FRAME
LM LMOD
Frame/logo
mode.
Rd/Wr
0
3
0 = use & assignment mode.
1 = logo recording mode.
2 = frame recording mode.
3 = erasing mode.
LX
LSTA
Status of the logo programmer
Rd
0 4
0 = free.
1 = logo/frame in recalling process.
2 = logo/frame in storing process.
3 = output format incompatible with the logo.
4 = logo/frame in erasing process.
LA
LPGA
Logo 1 & frame assignment.
Rd/Wr
0
10
LB
LPGB
Logo 2 & frame assignment.
Rd/Wr
0
10
0 = none
1 = frame 1
2 = frame 2
3 = logo 1
4 = logo 2........ 10 = logo 8
LC LCUR
• In logo recording mode: Number of
the logo to be store (3 to 10).
• In frame recording mode: Number of
the frame to be store (1 or 2).
• In erase mode: number of the logo to
be erase (0 = erase all).
Rd/Wr
0 10
0 = no logo
1 = frame 1
2 = frame 2
3 = logo 1
4 = logo 2................... 10 = logo 8
LD
LDYS
Display logo (according to PCH)
Rd/Wr
0
1
0 = Display OFF
1 = Display ON
LU
LHCP
Horiz. position of the logo storing area. Rd/Wr
0
255
Lu
LVCP
Vert. position of the logo storing area. Rd/Wr
0
255
LW
LHSA
Horizontal size of the logo storing area. Rd/Wr
5
255 5 = 3%
255 = 100%
LS
LVSA
Vertical size of the logo storing area.
Rd/Wr
5
255 5 = 3%
255 = 100%
LH
LHPA
Horizontal position of the logo 1.
Rd/Wr
0
255
Lh
LHPB
Horizontal position of the logo 2.
Rd/Wr
0
255
LV
LVPA
Vertical position of the logo 1.
Rd/Wr
0
255
Lv
LVPB
Vertical position of the logo 2.
Rd/Wr
0
255
LP
LPXA
Pixels number in a line of the logo 1.
Rd
0 65535
LL
LLNA
Lines number in a logo 1.
Rd
0 65535
These 2 commands allow calculating the
duration of the storing.
Lp
LPXB
Pixels number in a line of the logo 2.
Rd
0 65535
Li
LLNB
Lines number in a logo 2.
Rd
0 65535
These 2 commands allow calculating the
duration of the storing.
LT
LTYA
Logo 1 type.
Rd/Wr
0
1
0 = frame
1 = logo
Lt
LTYB
Logo 2 type.
Rd/Wr
0
1
0 = frame
1 = logo
LO
LOFA
Output format during the logo1 storing. Rd
0 11
Lo
LOFB
Output format during the logo2 storing. Rd
0 11
Identical as F command.
LR LSTO
• In recording mode: frame/logo storing.
• In erase mode: frame/logo erasing.
Rd
0 1
1 = STORE (automatic reset).
1 = ERASE (automatic reset).
Lr
LABT
Stop the frame storing.
Rd/Wr
0
1
1 = stop the frame storing (automatic reset).
MAIN / OUTPUT 1
LZ
LPTM
Logo transparency
Rd/Wr
0
15 0 = mini
15 = maxi
LE
LLEV
Luma key level.
Rd/Wr
0
255
lE LEMP
Status of the frame/logo memories.
(according to LCUR)
Rd
0 1
0 = logo/frame memorized.
1 = empty memory.
Lb LBKC
Background
color.
Rd/Wr
0
7
Ld
LLD
Fade logo duration (0.01 second step). Rd/Wr 15
255 15 = 0.15 second
255 = 2.5 seconds
Lf
LFD
Fade frame duration (0.1 second step). Rd/Wr
5
50 5 = 0.1 second
50 = 5 seconds
NOTE: To store a logo from the MAIN display you should:
c Select the logo recording mode with the LM command (1LM).
d Adjust the position and size of the logo storing area with the LU, Lu, LW and LS commands.
e Adjust the luma key level (with LE command) and the background color (with Lb command).
f Select a logo memory with the LC command and make a store with LR command (1LR).
To store a frame from the MAIN display you should:
c Select the frame recording mode with the LM command (2LM), and make a store with the LR command (1LR).
NOTE: To assign a logo/frame to an input on the MAIN display you should:
c Select the assignment mode with the LM command (0LM).
d Select a stored logo/frame with LA or LB commands.
e Adjust the horizontal & vertical position of the logo with the LH, Lh, LV & Lv commands.
