CENTRIX™ & EVENTIX™
PAGE 38
Chapter 4 : UPDATING
The CENTRIX ™ / EVENTIX ™ can be update thanks a COMPUTER (PC) via its REMOTE (RS-232) connector.
4-1. CONNECTIONS
c Connect the "REMOTE CONTROL RS-232" connector of the device to the SERIAL port of your COMPUTER
with a DB9 M/F straight cable.
d Connect the device to an AC power outlet.
e Switch OFF the device (rear panel switch = O).
Figure 33: Updating.
4-2. UPDATE INSTRUCTIONS
c Open the file "iX updater" (in start/Program/ANALOG WAY/iX8022).
d Click on "START" on the SOFTWARE.
e Switch ON the device. The POWER LED blinking slowly and the update will start.
f When the software displays "Program operation completed", SWITCH OFF and ON the device with the rear panel
switch.
g Click on the "QUIT" button to close the update software.
NOTE: Your CENTRIX
™ / EVENTIX ™ is now ready to work.
NOTE: The updater files are available on our web site: http://www.analogway.com
